نقد و بررسی سوئیچ سیسکو مدل WS-C3750G-24T-S:
سوئیچ مدل WS-C3750G-24T-S سیسکو تکنولوژیهای نسل آتی را در سوئیچهای دسکتاپ معرفی و به کار میگیرد و همچنین از فناوری Cisco StackWise، یک پورت پشته 32 گیگابیت بر ثانیه استفاده میکند که به کاربران حوزه مدیریت IT این امکان را داده که یک سوئیچ یکپارچه و بسیار منعطف را در آن واحد پیکربندی نمایند. سوئیچ سیسکو کاتالیست Cisco Catalyst 3750G-24TS یکی از بهترین انواع سوئیچهای سیسکو در ردههای مدلهای مربوط به کسب و کارهای متوسط میباشد. سوئیچ سیسکو 3750 دارای با قابلیت عملکرد در لایه سوم شبکه، امکانات زیادی اعم از IP Routing گسترده را دارا میباشد.
قابلیتها و ویژگیهای فنی سوئیچ سیسکو WS-C3750G-24T-S:
- 24 عدد پورت 10/100/1000
- استاندارد IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
- پروتکل روتینگ: HSRP, RIP-1, RIP-2, RIPng, static IP routingCLI, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 1, SNMP 2c, SNMP 3, SSH, Telnet
- حوزه عملکرد لایه 3
- حداکثر تعداد دستگاه قابل پشتیبانی برای پشته (Stack) --> نه ( 9 ) عدد
- 16 مگا بایت حجم حافظه فلش
- ویژگیها: ARP support, Access Control List (ACL) support, Cisco EnergyWise technology, Cisco StackWise Technology, DHCP support, Dynamic SMI,Trunking Protocol (DTP) support, IGMP snooping, IP-routing, Jumbo Frames support, Link Aggregation Control Protocol (LACP), Multiple Spanning Tree Protocol (MSTP) support, Port Aggregation Protocol (PAgP) support, Quality of Service (QoS), RADIUS support, Rapid Per-VLAN Spanning Tree Plus (PVRST+), Rapid Spanning Tree Protocol (RSTP) support, Remote Switch Port Analyzer (RSPAN), Spanning Tree Protocol (STP) support, Trivial File Transfer Protocol (TFTP) support, Uni-Directional Link Detection (UDLD), VLAN support, auto-negotiation, auto-sensing per device, auto-uplink (auto MDI/MDI-X), flow control, full duplex capability, layer 3 switching, stackable, traffic shaping
- ولتاژ AC 120/230 V
- 1.7*12.8*17.5 اینچ
Cisco Catalyst 3750 Series switch 3750G-24T is an innovative product line that improves LAN operating efficiency by combining industry-leading ease of use and the highest resiliency available for stackable switches. This new product series represents the next generation in desktop switches, and features Cisco StackWise technology, a 32-Gbps stack interconnect that allows customers to build a unified, highly resilient switching system - one switch at a time. For mid-sized organizations and enterprise branch offices, the Cisco Catalyst 3750 Series eases deployment of converged applications and adapts to changing business needs by providing configuration flexibility, support for converged network patterns, and automation of intelligent network-services configurations
Manufacturer | Cisco Systems, Inc |
Manufacturer Part Number | WS-C3750G-24T-S |
Product Type | Managed, Stackable 24 ports L3 Switch |
Form Factor | Fixed, Rack Mountable 1U, Stackable/Clustering |
Switch Port density - Uplinks | 24 x 10/100/1000 Ethernet Ports |
Performance | Switching capacity : 32 Gbps Forwarding performance : 35.7 Mpps |
MAC Address Table Size | 12K entries |
Jumbo Frame Support | Yes |
Max Number of Stacks | 9 |
Routing Protocol | RIP-1, RIP-2, HSRP, static IP routing, RIPng |
Remote Management Protocol | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, SSH, CLI |
Authentication Method | Kerberos, Secure Shell (SSH), RADIUS, TACACS+ |
Features | Flow control, full duplex capability, Layer 3 switching, auto-sensing per device, IP-routing, DHCP support, auto-negotiation, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, traffic shaping, stackable, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), RADIUS support, Jumbo Frames support, Cisco StackWise Technology, Cisco EnergyWise technology, Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Link Aggregation Control Protocol (LACP), Remote Switch Port Analyzer (RSPAN) |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s |
DRAM Memory | 128 MB |
Flash Memory | 16 MB Flash |
LED Status Lights Indicators | Link activity, port transmission speed, port duplex mode, bandwidth utilization %, system, RPS (Redundant Power Supply) |
Interfaces | 24 x 10Base-T/100Base-TX/1000Base-T - RJ-45 1 x console - RJ-45 - management Network stack device : 1 x x 2 |
Power Device | Power supply - internal |
Voltage Required | AC 120/230 V ( 50/60 Hz ) |
Power Consumption Operational | 165 Watt |
Features | Redundant Power System (RPS) connector |
Width | 44.5 cm |
Depth | 32.6 cm |
Height | 4.4 cm |
Weight | 4.6 kg |
MTBF | 210,936 hour(s) |
Compliant Standards | CE, FCC Class A certified, TUV GS, BSMI CNS 13438 Class A, CISPR 24, cUL, EN 60950, EN55022, NOM, VCCI Class A ITE, IEC 60950, EN55024, UL 60950 Third Edition, CISPR 22, CSA 22.2 No. 60950, CB, FCC Part 15, MIC, AS/NZS 3548 |
Software Included | Cisco IOS IP Base |
